XLERATOR XL-BW Hand Dryer (White Thermoset) Excel Dryer

The XLERATOR XL-BW is the flagship high-speed hand dryer from Excel Dryer — the original American-made XLERATOR in white thermoset resin, backed by Excel Dryer's 7-year limited warranty and Made in USA Certified® manufacturing. Independent SGS testing shows the standard XLERATOR dries hands in 8 seconds¹ at just 3.7 Wh of energy per use. That speed helps support high-traffic restroom throughput in busy facilities like airports, stadiums, schools, malls, and office buildings. As an Authorized Stocking Distributor with a Low Price Guarantee, Total Restroom offers the XL-BW in multiple voltage configurations and ships from a U.S. distribution network.

Looking for the lower-energy version? See the XLERATOReco XL-BW-ECO — same white thermoset resin cover, 500W no-heat operation for LEED-focused projects.

Specifications

• Model / MPN: XL-BW (XLERATOR Hand Dryer)
• Cover finish: White Thermoset Resin (BMC)
• Activation: Automatic sensor-operated, with adjustable sensor range
• Mounting: Surface-mounted
• Dimensions: 11-3/4" W × 12-11/16" H × 6-11/16" D (298 × 322 × 170 mm)
• Dry time: 8 seconds¹
• Energy per use: 3.7 Wh
• Adjustable sound level: 65–75 dB
• Adjustable air velocity: 13,000–20,000 LFM
• Flow rate: 42–63 CFM
• Adjustable heat range: 72°F–135°F
• Heat settings: High, Medium, Low & Off
• Voltage options: 110-120V or 208-277V standard multi-voltage options; other configurations may be available by order
• Frequency / phase: 50/60 Hz, single phase
• 110-120V load: 11.3–12.2 amps and 1,213–1,450 watts (heat off: 4.3-4.5A / 442-513W)
• 208-277V load: 5.6–6.2 amps and 1,135–1,450 watts (heat off: 2.0-2.2A / 416-495W)
• Service indicator: Externally Visible Service LED
• Filtration: Washable pre-filter (standard); optional eHEPA® electrostatic HEPA
• Warranty: 7-year limited (Excel Dryer)
• Country of origin: Made in USA Certified®
• Listings & certifications: Smart EPD® verified Environmental Product Declaration; GreenSpec Listed
• Shipping weight: 15.0 lb (6.8 kg)

Key Features

8-Second Dry Time at 3.7 Wh Energy Use
The standard XLERATOR is engineered for throughput. Independent SGS International testing — performed on the standard XLERATOR with a 0.8" nozzle to 0.25g or less of residual moisture, per the UL Environment Global Product Category Rules for hand dryers — confirms an 8-second dry time at just 3.7 Wh per use. That speed helps support high-traffic restroom throughput in busy facilities.

Adjustable Heat Plus Speed and Sound Control
The standard XLERATOR includes adjustable heat in addition to adjustable speed, sound, and sensor range. Heat range runs 72°F–135°F with High, Medium, Low and Off settings, sound is field-adjustable from 65–75 dB, and air velocity is adjustable from 13,000–20,000 LFM. The same SKU works in a noisy stadium concourse and a quieter office washroom — installers tune it to the room.

7-Year Limited Warranty, Made in USA Certified®
Excel Dryer backs the XLERATOR with a 7-year limited warranty. Every XLERATOR is built in the United States and carries Made in USA Certified® designation. The white thermoset resin cover is well suited for daily commercial restroom use.

Externally Visible Service LED
An externally visible Service LED lets maintenance staff identify a fault condition without opening the unit or interrupting service. Combined with the washable pre-filter, this design keeps maintenance simple — wipe down, inspect, return to service.

Optional eHEPA® Filtration and 1.1" Noise Reduction Nozzle
Two factory-orderable upgrades extend the platform: the eHEPA® electrostatic HEPA filtration system removes 99.999% of viruses and 99.97% of potentially present bacteria at 0.3 microns from the airstream² (-H suffix), and the 1.1" Noise Reduction Nozzle drops sound output by 9 decibels while adding only about 3 seconds to dry time (-1.1N suffix). Specify these at order time.

LEED, WELL, and EPD Documented
Excel Dryer received the industry's first certified Environmental Product Declarations (EPDs) under the UL Environment global PCR for hand dryers. The XLERATOR family helps contribute to WELL Building Standard points and several LEED® credits. The XL-BW is GreenSpec Listed.

Which Finish Is Right For You?

The XL-BW is the white thermoset resin (BMC) finish — the lightest XLERATOR cover at 15 lbs, molded from a durable resin and the most economical white option. The XLERATOR family ships in five standard finishes plus two custom options:

• XL-BW — White Thermoset Resin (BMC) (this page)
• XL-W — White Epoxy Painted
• XL-SB — Brushed Stainless Steel
• XL-C — Chrome Plated
• XL-GR — Graphite Textured Painted

Custom Special Paint and Custom Special Image covers are also available — call us for branded or color-matched orders.

Standard XLERATOR or XLERATOReco?

If your priority is fast throughput and you need heated drying, the standard XLERATOR is the right SKU. If your priority is energy savings, lower utility bills, LEED contribution, or quieter operation, look at the XLERATOReco instead. Both share the same 11-3/4" × 12-11/16" footprint, the same 7-year warranty, and the same range of cover finishes — the Eco runs at 500W with no heat and trades a few seconds of dry time for substantially lower energy use. If your priority is fastest throughput with heat, the XL-BW is the right SKU. If you want the lower-energy version, see the XLERATOReco XL-BW-ECO in the same white thermoset resin finish.

Installation Guidance

The XL-BW is surface-mounted and designed for commercial restroom installation. Excel Dryer's suggested mounting heights, measured from the floor to the bottom of the dryer, are 45" (114 cm) for men's washrooms, 43" (109 cm) for women's washrooms, and 37" (94 cm) for accessible installations. A dedicated 20-amp circuit is recommended for 110-120V installs; the 208-277V configurations draw 5.6–6.2 amps / 1,135–1,450 watts. Allow appropriate clearance on either side and below the unit so the air stream and sensor work as designed.

For ADA-compliant installations where the dryer must project less than 4 inches from the wall, order the optional ADA-Compliant Recess Kit (#40502) — the standard XL-BW projects 6-11/16" (170mm) and is not ADA-compliant on its own. If you're retrofitting into a paper-towel cabinet location, the XChanger® retrofit kit (#40575 or #40550) drops the XLERATOR into a recessed cavity. Antimicrobial Wall Guards (#89B/W/S) are available for high-touch and high-traffic locations.

Frequently Asked Questions

How long does the XL-BW take to dry hands?
The XLERATOR dries hands in 8 seconds, per independent SGS International testing. That test is performed to 0.25g or less of residual moisture, following the UL Environment Global Product Category Rules for hand dryers. Real-world dry times will vary slightly with technique, room conditions, and selected speed settings.

What voltage does the XL-BW use?
The XL-BW is multi-voltage with two standard options: 110-120V and 208-277V at 50/60 Hz, single phase. At 110-120V the unit draws 11.3–12.2 amps and 1,213–1,450 watts; at 208-277V it draws 5.6–6.2 amps and 1,135–1,450 watts. Other voltage configurations (208-240V, 230V) may be available by order. A dedicated 20-amp circuit is recommended for 110V installs. Pick the voltage option that matches the circuit available at the install location.

Is the XLERATOR XL-BW ADA-compliant?
Not on its own — the XL-BW projects 6-11/16" (170mm) from the wall, which exceeds the 4" projection limit for accessible routes. To make the XL-BW ADA-compliant, install Excel Dryer's optional ADA-Compliant Recess Kit (#40502), which recesses the unit into the wall. Final ADA compliance also depends on mounting height and clear floor space at the installed location.

Can I adjust the speed and sound on the XL-BW?
Yes. The XLERATOR has field-adjustable settings for sound level (65–75 dB), air velocity (13,000–20,000 LFM), air flow rate (42–63 CFM), and sensor pickup range. Heat is also adjustable across 72°F–135°F with High, Medium, Low and Off settings. That means the same XL-BW can be dialed quieter for a hotel washroom or louder and faster for a stadium concourse.

Does the XLERATOR have HEPA filtration?
HEPA is an optional upgrade — order the -H suffix to add the eHEPA® electrostatic HEPA filtration system. Per LMS Technologies testing in 2023, the eHEPA filter removes 99.999% of viruses and 99.97% of potentially present bacteria at 0.3 microns from the airstream. The standard XL-BW ships with a washable pre-filter; the eHEPA upgrade adds the electrostatic stage on top.

Does the XLERATOR qualify for LEED or WELL credits?
Yes. Excel Dryer holds the industry's first certified Environmental Product Declarations (EPDs), verified by Smart EPD® under the UL Environment global Product Category Rules for hand dryers. The XLERATOR family helps contribute to multiple LEED® credits and WELL Building Standard points. Excel Dryer can provide LEED v4 and v4.1 credit summaries, EPDs, HPDs, and life-cycle assessment documentation to support project documentation.

What's the warranty?
Excel Dryer covers the XLERATOR XL-BW with a 7-year limited warranty. Coverage details and registration are available directly from Excel Dryer.

Should I choose the standard XLERATOR or the XLERATOReco?
If your priority is fast throughput and you need heated drying, the standard XLERATOR is the right SKU. If your priority is energy savings, lower utility bills, LEED contribution, or quieter operation, look at the XLERATOReco instead. Both share the same 11-3/4" × 12-11/16" footprint, the same 7-year warranty, and the same range of cover finishes — the Eco runs at 500W with no heat and trades a few seconds of dry time for substantially lower energy use.

¹ Dry time and energy use testing performed by SGS International on XLERATOR Hand Dryer to 0.25g or less of residual moisture, pursuant to the UL Environment Global Product Category Rules (PCR) for Hand Dryers.
² Based on testing performed by LMS Technologies, 2023.
