Zurn One Manual Wall Mounted Service Sink System with 6.5 GPF Flush Valve with Bedpan Washer
ARCHITECTURAL & ENGINEERING SPECIFICATION
Complete AquaVantage® 4.5 gpf manual actuated wall mounted service sink system with Z60843AV-BWN-FF exposed, manually activated chrome-plated closet flushometer with bedpan washer for either left or right hand supply, and Z5410 wall mounted vitreous china service sink, Z85500-WM self-closing double pedal mixing valve with Z5977-NEO closet flange outlet gasket assembly kit manufactured by Zurn.
PRODUCT FEATURES
• 4.5 gpf (gallons per flush)
• Wall mounted service sink
• Siphon jet flush action
• Integral flushing rim
• Water surface: 10” x 10”
• Vitreous china
• Diaphragm- type flushometer complete with Zurn’s Go Blue® TPE, chloramine resistant, dual seal diaphragm with a clog resistant filtered by-pass.
• Non-hold open, dual seal handle
• High pressure vacuum breaker
• Adjustable tailpiece
• Control stop with internal siphon guard protection, vandal resistant cap, sweat solder kit and cast wall flange with set screw
COMPLIANCE AND CERTIFICATION
Meets the American Disabilities Guidelines and ANSI A117.1 requirements when installed according to these requirements.
• Fixture - Complies with ASME A112.19.2 / CSA B45.1
• Flush Valve - Complies with ASSE 1037 / ASME A112.1037 / CSA B125.37
• Faucet - Complies with ASME A112.18.1 / CSA B125.1
WARNING: California Residents
This product and/or packaging can expose you to chemicals including Styrene, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
