Koala Kare KB200-05SS Flush Mount Horizontal Stainless Steel Veneer and Polypropylene, Updated Part Number: KB300-05SS

✅ Durable stainless steel, one-piece construction

✅ Microban® surface protection reduces bacteria and odor

✅ Dual liner cavity with external bag hook

✅ ADA, ASTM, and ANSI compliant when installed correctly

✅ Easy-to-clean, bacteria-resistant polypropylene interior

✅ Pneumatic cylinder for smooth opening and closing

✅ Dual cavity liner dispenser holds ~50 liners for less frequent maintenance

Recessed-mounted horizontal baby changing station features one-piece, deep-drawn, uniform grain stainless steel components eliminate seams, sharp edges and weld lines, and provide a modern visual aesthetic. Thoughtful patron amenities enhance the end-user experience, and include Microban® product protection, laser etched logo, a redesigned liner dispenser and a convenient stainless steel bag hook for safely storing a diaper bag off the floor.

The dual liner cavity has an internal spring tab that pushes liners forward while only allowing single liner dispensing. Each cavity holds 25 liners and locking mechanism minimizes operator refills and discourages potential vandalism. The product includes child protection straps and bag hooks. Bed surface exclusively contains Microban® antimicrobial, reducing odor causing bacteria.

✅ Superior Strength and Durability:
This premium baby changing station is crafted with an internal steel frame and durable polypropylene plastic, ensuring longevity and resilience in high-traffic areas.

✅ Hygienic and Safe:
Features Microban product protection to reduce odor. Child protection straps and a concealed pneumatic cylinder for smooth, controlled opening and closing for added safety during use.

✅ Complements modern restroom design and décor:
Stainless Steel veneer with Grey or White Granite plastic body is a design upgrade that will give your restroom a more glamourous look.

✅ User-Friendly Convenience:
Equipped with dispensers for easy access to sanitary liners and diaper disposal sacks. As well as a stainless bag hook that mounts on wall next to station for safe and easy access to diaper bags and purses.

Material
Grey injection-molded polypropylene with Microban® antimicrobial additive embedded into the bed surface. Reinforced steel-on-steel hinge mechanism and plated or powder coated steel mounting chassis with mounting hardware included. Satin finished 304 stainless steel deep drawn outer shell and recessed pan. Injection molded aluminum handles with satin stainless steel finish. Solid stainless steel external bag hook. Labeled usage instructions and safety messages. Contoured changing surface area 535 sq. In (3452 sq. cm) and comes complete with safety strap. Dual cavity liner dispenser holds approximately 50 KB150-99 bed liners.

Operation
Concealed pneumatic cylinder and metal mounting chassis provides controlled, slow opening and closing of bed. Polypropylene is easy to clean and resists odors and bacterial growth. Complies with ASTM static load performance requirements when properly installed. Internal liner dispenser with integrated spring tab dispensed one liner at a time. Handles guide patron to operate unit with less than 5lbs of force and act as cane detection if unit is left in open (down) position.

Warning: To ensure that the unit supports the intended loads, baby changing stations must be properly installed according to the manufacturer’s instructions.

Specification
Baby changing station shall have durable, single piece deep drawn 304 satin finished stainless steel outer shell and recessed pan, with injection-molded polypropylene interior. Design of unit shall be recess-mounted. Unit shall be equipped with a pneumatic cylinder for controlled opening and closing of bed. Bed shall be secured to metal mounting chassis with a concealed steel-on-steel hinge. No hinge structure shall be exposed on interior or exterior surfaces. Unit shall have mounting hardware included. Unit shall have Microban® antimicrobial embedded into plastic material on the changing surface. Unit shall fully comply with ADA regulations when properly installed. Bed shall have smooth concave changing area with a safety strap and external stainless steel hook for bags or purse provided.

The design and manufacture of Koala products is intended to be compliant with the 2010 ADA Standards for Accessible Design and the 2009 ICC A117.1, Accessible and Usable Buildings and Facilities. Unit shall conform to ASTM F2285-04(16) Standard Safety Performance Specification for Diaper Changing Tables for Commercial Use, ANSI Z535.4 Product Safety Signs and Labels, EN 12221:2008+A1: 2013. Unit shall have a built-in Liner Dispenser for use with 3-ply chemical free biodegradable bed liners, instructional graphics and safety messages in 4 languages. Unit shall be backed by manufacturer’s 5-year limited warranty on materials and workmanship and include a provision for replacement caused by vandalism.
